60 Mini PIR Alarm Sensor

SKU: PIR43

  • Compact, wide detecting area
  • Portable and easy to install
  • Ideal for commercial use
  • Functions as an annunciator as well as an alarm
  • Detection moving speed 0.6 – 1.5m/s
  • Unit can be installed on a wall horizontally or vertically or simply place on a desktop
  • Uses 1 x 9V Battery (not included)

R 285.00 ex. VAT R 327.75 in. VAT
Out of Stock
Contact Us

Details

The PIR43 Mini Alarm Sensor is a pocket sized, dual-pyroelectric infrared sensor alarm that provides reliable detection all day long. The PIR43 uses a high sensitivity detector, an integrated circuit and SMT technology to detect movement of people and vehicles, while allowing small animals to pass through undetected. The unit is easy-to-install, automatic, convenient, and has a safety and practical function. The wide detection range consists of horizontal and vertical detection fields. It utilises human motion infrared rays as control signals and sounds the alarm when motion is detected. This unit’s convenient size makes it perfect for concealing and travelling.

Specifications:

Function Range
Detection Angle 180°
Detection Range 12m
Detection Type PIR
Installation Height 1.8m to 2.5m
No. PIR Detectors 1 Detector
Protection Grade IP44
Rated Load Energy Save Max: 400 Watts
Rated Load Incandescent Min: 800 Watts
Time Delay 10s, 30s, 90s, 3m, 7m & 15m (2± min)
Working Voltage AC220 – 240V

Safety Rating
