1000A AC True RMS Clamp Meter

SKU: MT770

  • 6000 count backlit LCD display
  • Ø33mm Cable Clamp size
  • Measurement of DC voltage and AC TRMS voltage up to 1000V
  • Capacitance to 100mF
  • Temperature measurement from -20⁰C to 1000⁰C
  • INRUSH Current Measurements
  • VFD – Variable Frequency Drive voltage value
  • LoZ – Low impedance mode prevents false readings due to “Ghost” voltage
  • NCV – Non-Contact Voltage Detector
  • Built-In Flashlight
  • Continuity buzzer and Diode Test
  • Peak Mode and Data Hold function
  • Auto Power Off

R 2 730.00 ex. VAT R 3 139.50 in. VAT
Add to Cart

Details

The MT770 is a CAT IV 600V, 6000 count True RMS 1000A AC digital clamp meter with indication on a large backlit LCD display, providing fast
sampling time with high accuracy. The meter measures 1000V AC/DC, temperature, frequency, capacitance and resistance measurements,
100ms Inrush current and Peak Voltage value. The VFD function allows the user to measure stable voltage in high frequency applications of
Variable Frequency Drives, while the Low Z range function has a low pass filter to eliminate errors caused by “Ghost” voltages. Added features
include Relative mode for Capacitance Zero, DCV, ACV and ACA offset adjustment, Non-Contact voltage detection, Data hold function and a
built-in flashlight for dimly lit areas. Housed in a modern double moulded rubber housing.



Specifications:

Function Range Resolution Accuracy
AC Current 0.1A – 1000.0A 10mA ±(2.5% + 8 Digits)
DC Voltage 0.1mV – 1000V 1mV ±(1.5% + 2 Digits)
AC Voltage 1mV – 1000V 1mV ±(1.5% + 5 Digits)
Resistance 0.1Ω – 60.00MΩ 0.1Ω ±(1.5% + 2 Digits)
Frequency 0.001Hz – 99.99kHz 0.01Hz ±(1.2% + 5 Digits)
Capacitance 0.01nF – 100mF 0.01nF ±(3.0% + 5 Digits)
Temperature -20 to 1000°C 0.1°C ±(3.0% + 5°C Digits)
Duty Cycle 10% to 90% 0.001 ±(1.2% + 2 Digits)
True RMS Measurements ACV, ACA
AC Bandwidth 50 – 400Hz
Digital Display 6000
Non-Contact Voltage (NCV) Yes
Overrange Indication Yes
Continuity Yes
Diode Test Yes
Jaw Size 33mm
Input Impedance >10MΩ DCV & >10MΩ VAC
Low Frequency Input Yes
Min Max Yes
Peak Hold Yes
Data Hold Yes
Back Light Yes
Enclosure Double injection moulding
Low Battery Indication Yes
Batteries 3 x AAA
Weight 350g
Dimensions 250 x 70 x 40mm
Safety Specs IEC61010-1 CAT IV 600V

Safety Rating

Warranty

Accessories:

  • Test Leads
  • Type-K Wire Probe
  • Type-K Adaptor
  • Carrying Case
  • 3 x AAA Batteries
  • Instruction Manual
