Magnetic Solenoid Tester
R378.35
Features :
- Easy-to-use
- Built-in LED flashlight
- Red LED light with audible beeper indicator
- All outer surfaces are non-conductive for safety
- Detects AC current without metallic contact
- Test magnetic field (H): 63, 98, 401, 810
The MT123 is a pocket-sized magnetic solenoid tester that responds to all kinds of magnetic fields. It is easy-to-use. Just touch the tip to an outlet or cord, when the tip glows red it indicates voltage in the line.
Accessories:
AAA Batteries
Instruction Manual
General Application:
- Testing operating solenoid valves in pneumatic and hydraulic control equipment.
- Testing relays with coils and electrically controlled solenoid valves in all types of vehicles and machineries.
- Testing solenoid valves when servicing oil burners, the test lamp lights immediately and without metallic contact when there is a magnetic field, e.g. and activated coil in a solenoid valve.
- The test lamp responds to all kind of magnetic fields – from alternating current to direct current and to permanent magnets.
Downloads
[/vc_column][/vc_row]Additional information
| Weight | 48g |
|---|---|
| Dimensions | 158 x 21 x 25mm |
| Enclosure | Double moulded |
| Humidity | 95% (0°C to 40°C) |
| Power | 3V (2 x AAA Batteries) |
| Flash Light | Yes |
| Magnetic Detector Visual | Red LED |
| Magnetic Field | 63, 98, 401, 810 |
| Maximun working current | 32mA |
| Operation Temperature | -10°C to 50°C |
| Power source | 2 x R03 |
| Safety Specs | IEC61010-1 CatIV 600V |
| Storage temperature | -10°C to 50°C |
