2-In-1 Tone and Probe and Multimeter
R2,472.50
Features :
- CATIII 300V and CAT II 600V
- Tests include wire trace, continuity test, clear/busy/ringing line test and tip/ring identification
- Alligator clips for non-terminated cables and modular connectors for direct connections to telephone or internet wiring
- Built-in speaker on probe with sensitivity control
- Selectable continuous or variable tone generation
- Insulated inductive probe tip prevents shorting conductors
- Measures ACV and DCV up to 600V, ACA and DCA up to 200mA, Resistance to 20MΩ, Diode and Continuity
- RJ11 Modular Connectors
The MTC45 is a 2-in-1 Tone and Probe generator as well as an auto ranging multimeter. The meter tests include wire trace, continuity test, clear/busy/ringing, line test and tip/ring identification. The unit is supplied with crocodile clips for non terminated cables and modular connectors for direct connections to telephone and internet wiring. The auto range digital multimeter can measure AC/DC volts, AC/DC current, Resistance, Diode and has a continuity buzzer.
Accessories:
Carrying Case
2 x AAA and 2 x 9V
Test Leads
Crocodile Clips
Instruction Manual
Additional information
| DC Voltage | 200.0mV – 600V |
|---|---|
| DC Voltage resolution | 0.1mV |
| DC Voltage accuracy | ±(1.0% +3) |
| AC Voltage | 200mV – 600V |
| AC Voltage resolution | 1mV |
| AC voltage accuracy | ±(1.0% +5) |
| DC Current | 200.0μ A – 200.0mA |
| DC Current resolution | 0.1µA |
| DC Current accuracy | ±(1.5% +3) |
| AC Current | 200.0μ A – 200.0mA |
| AC current resolution | 0.1µA |
| AC Current accuracy | ±(1.8% +8) |
| Resistance | 200.0Ω – 20MΩ |
| Resistance resolution | 0.1Ω |
| Resistance accuracy | ±(1.2% +3) |
| Over-range indication | >7.5MΩ VDC & >7.5MΩ VAC, Yes |
| AC Bandwidth | 50Hz-60Hz |
| Continuity | Yes |
| Diode Test | Yes |
| Digital Display | 2000 |
| Tone and Probe Tester | Cable and Wire; RJ11 |
| Min Max | Yes |
| Back Light | Yes |
| Enclosure | Rubber Holster |
| Power source | 2 x AAA and 2 x 9V |
| Weight | 328g |
| Dimensions | 162 x 74 x 43mm |
| Safety Specs | IEC 61010-1 CATIII 300V |
